華為交換機s5700怎麼清除密碼（老舊S5300EI清除密碼方法）

2023-10-18 18:05:13 3

華為交換機s5700怎麼清除密碼?這種老舊交換機官方已停止支持，官方文檔關於怎麼進隱藏模式沒有說明這裡做了操作示範：，我來為大家講解一下關於華為交換機s5700怎麼清除密碼?跟著小編一起來看一看吧!

華為交換機s5700怎麼清除密碼

這種老舊交換機官方已停止支持，官方文檔關於怎麼進隱藏模式沒有說明。這裡做了操作示範：

使用console線連接設備，使用secureCRT設置波特率9600，設備加電啟動，

Reboot...

BIOS LOADING ...

Copyright (c) 2008-2009 HUAWEI TECH CO., LTD.

CX22EMGE (Ver015, Nov 4 2009, 16:41:54)

Press Ctrl B to enter BOOTROM menu... 2 #在此按鍵盤的Ctrl B進入bootrom

password: #輸入密碼，默認為huawei

BOOTROM MENU

1. Boot with default mode

2. Enter serial submenu

3. Enter startup submenu

4. Display flash files

5. Modify BOOTROM password

6. Reboot

Enter your choice(1-6): #在此按鍵盤的Ctrl Z進入隱藏菜單

HIDDEN MENU

1. Erase Flash

2. Delete file from Flash

3. Format flash

4. Enter ethernet submenu

5. Update EPLD file

6. Update FPGA file

7. Update FansCard File

8. Return to main menu

Enter your choice(1-8): 2 #輸入2刪除文件

No. File Size(bytes) Created Date File Name

=================================================================

1: 9348204 bytes Oct 01 2008 00:17:57 flash:/SV100R002C02B093_for_5300.cc

2: 60 bytes Oct 01 2008 00:20:03 flash:/$_patchstate_a

3: 28 bytes Oct 01 2008 00:00:57 flash:/private-data.txt

4: 836 bytes Oct 01 2008 00:01:18 flash:/rr.dat

5: 836 bytes Oct 01 2008 00:01:22 flash:/rr.bak

6: 4 bytes Oct 01 2008 00:20:37 flash:/notilogindex.txt

7: 6188 bytes Oct 01 2008 00:28:44 flash:/vrpcfg.cfg

BE CAREFUL!

This may cause your system fail to start!

Please input the full directory and filename you want to delete, e.g.: flash:/hw-switch.cc flash:/vrpcfg.cfg #輸入要刪除的配置文件路徑和文件名，此處為flash:/vrpcfg.cfg

delete it? Yes or No(Y/N)y #輸入Y回車，確認刪除

Deleting file .....done

HIDDEN MENU

1. Erase Flash

2. Delete file from Flash

3. Format flash

4. Enter ethernet submenu

5. Update EPLD file

6. Update FPGA file

7. Update FansCard File

8. Return to main menu

Enter your choice(1-8): 8 #輸入8回車回到上級菜單

BOOTROM MENU

1. Boot with default mode

2. Enter serial submenu

3. Enter startup submenu

4. Display flash files

5. Modify BOOTROM password

6. Reboot

Enter your choice(1-6): 4 #輸入4回車，檢查配置文件是否被刪除

No. File Size(bytes) Created Date File Name

=================================================================

1: 9348204 bytes Oct 01 2008 00:17:57 SV100R002C02B093_for_5300.cc

2: 60 bytes Oct 01 2008 00:20:03 $_patchstate_a

3: 28 bytes Oct 01 2008 00:00:57 private-data.txt

4: 836 bytes Oct 01 2008 00:01:18 rr.dat

5: 836 bytes Oct 01 2008 00:01:22 rr.bak

6: 4 bytes Oct 01 2008 00:20:37 notilogindex.txt

Total: 30008KB(Free: 20848KB)

BOOTROM MENU

1. Boot with default mode

2. Enter serial submenu

3. Enter startup submenu

4. Display flash files

5. Modify BOOTROM password

6. Reboot

Enter your choice(1-6):6 #確認文件刪除，輸入6回車重啟

Reboot...

BIOS LOADING ...

Copyright (c) 2008-2009 HUAWEI TECH CO., LTD.

CX22EMGE (Ver015, Nov 4 2009, 16:41:54)

Press Ctrl B to enter BOOTROM menu... 1

Auto-booting...

Update Epld file ............................ None

Update ForeCard FPGA file ................... Success

Update FansCard file ........................ None

Decompressing VRP software .................. done

DOPRA_C Library release version 1.6.6.3, by DOPRA.

Copyright (C) 1999-2006 Huawei Technologies Co., Ltd.

DOPRA is a registered trademark of Huawei Technologies Co., Ltd.

This is commercial software; see the source for copying conditions.

There is NO warranty; not even for MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.

Initialize DOPRA root

Initialize FSP Task

Initialize hardwareInitialize VOS VFS

Initialize VOS monitor

Initialize CFM

CPLD testing ..................................... pass

Initialize device link

Create VRP task

Initialize VRP task

Register command lines

Awake task

Recover configuration...

Console 0 is available

Press ENTER to start

dir #在系統內確認配置文件被刪除

Directory of flash:/

0 -rw- 9348204 Oct 01 2008 00:17:57 SV100R002C02B093_for_5300.cc

1 -rw- 60 Oct 01 2008 00:20:03 $_patchstate_a

2 -rw- 28 Oct 01 2008 00:05:09 private-data.txt

3 -rw- 4 Oct 01 2008 00:20:37 notilogindex.txt

30008 KB total (20848 KB free)

dir /all

Directory of flash:/

0 -rw- 9348204 Oct 01 2008 00:17:57 SV100R002C02B093_for_5300.cc

1 -rw- 60 Oct 01 2008 00:20:03 $_patchstate_a

2 -rw- 28 Oct 01 2008 00:05:09 private-data.txt

3 -rwh 836 Oct 01 2008 00:05:18 rr.dat

4 -rwh 836 Oct 01 2008 00:05:24 rr.bak

5 -rw- 4 Oct 01 2008 00:20:37 notilogindex.txt

30008 KB total (20848 KB free)
